Multistage STwrench User Guide
142 (326) 9836 4134 01 Edition 2.9
The M: 0/3 indicates that the first Pset of the Multistage is being
executed.
If the Multistage batch size is greater than one, the batch count
number is displayed on the right-hand side of the bottom part of the
screen.
If the Multistage is Not OK, the batch number is not increased and the
Multistage must be repeated until the result is OK; if a Max coherent
NOK result is defined in the Multistage definition, when the number
of Not OK results reaches the maximum value, the following error
message is displayed:
For each tightening operation, the LEDs indicator, buzzer and vibration devices are activated according to
the tightening strategy selected.
The data and traces from the tightening results are stored automatically in the wrench memory; see the
Results Viewer and Traces Viewer chapters for information on how to retrieve results and traces using
ToolsTalk BLM.
