STwrench User Guide Offline Programming
9836 4134 01 Edition 2.9 189 (326)
The offline programming has the following limitations:
• TAG Writer: Since this function read and program in real time the end fitting tool plugged into the
STwrench smartHEAD, it is not possible to use it in the offline mode.
• Remote device communication: The offline mode can program the STwrench communication
parameters with the remote devices (Power Focus, ToolsNet, QATnode, API). However, once the
offline file is uploaded to the STwrench, the communication must be enabled with the STwrench
connected (as shown in the following example for Power Focus communication):
• The Power Focus pairing procedure cannot be perfomed offline.
The parameters can be
programmed offline
The enable connection flag
must be activated online
offline
