Atlas Copco STwrench User Manual

STwrench User Guide Introduction
9836 4134 01 Edition 2.9 19 (326)
• IRC-B radio module (optional):
- Frequency: 2.402 ÷ 2.480 GHz
- RF output power: max 16.9dBm (49mW)
- Receiver sensitivity: -89 dBm
- Receive input level (max): +16 dBm
• IRC-Z radio module (optional):
- Channels: 11 ÷ 26
- Frequency: 2.405 ÷ 2.480 GHz
- Channel separation: 5 MHz
- RF output power: max 4 dBm
- Receiver sensitivity: -100 dBm
- Receive input level (max): +10 dBm
• Barcode reader module (optional):
- Visible laser diode 650 nm
- Output power: 1 mW maximum
- Scan rate: 104 ± 12 scans/second (bi-directional)
- Scan angle: 47° ± 3°
- Scan patterns: Linear
- Minimum print contrast: Minimum 20% absolute dark/light reflectance
measured at 650 nm
- Ambient light:
- Sunlight: 10000 ft candles (107640 Lux)
- Artificial: 450 ft candles (4484 Lux)
- EMI/RFI: FCC Part 15 Class B, EN 55024/CISPR 22, AS 3548, VCCI
- Laser Safety: IEC 60825-1:2007 (CEI EN 60825-1:2009) class 1

Atlas Copco STwrench Specifications

General

Brand	Atlas Copco
Model	STwrench
Category	Tools
Language	English
