Results Viewer STwrench User Guide
194 (326) 9836 4134 01 Edition 2.9
To retrieve the results with ToolsTalk BLM, click on the Results viewer icon:
The following window is shown:
The result viewer provides results from Pset and Multistage only, and not Job results. All Job results are
grouped with the single Psets/Multistages making up the Job.
If a certain Pset/Multistage has changed its name after having executed at least one tightening, the old and
new names are both shown in description. In the example of the figure above, Pset number 1 was called
“Pset 1”, and then renamed as “Tightening test 1”.
Select the Psets/Multistages
