All of the information related to the tightening operation is displayed in the various columns.
Pset number
Pset number.
Status
This is the global status of the tightening operation. It is OK
when both the Torque Status and Angle Status are OK.
Torque Status / Angle Status
These fields indicate the result for the torque and angle. If the
result is not within the given limits, the field is colored
yellow and marked with LOW or colored in red and marked
with HIGH, according to the result status. If the angle is not
included in the control strategies, the angle status is colored
in grey and marked as N.A. (not applicable).
Result number
Progressive number automatically assigned by the wrench to
every tightening result.
Min value: 1
Max value: 5000
When 5000 results are stored in the wrench memory, the new
results overwrite the oldest starting from result number 1.
Torque result and Angle result
Torque and angle values measured by the wrench. They are
measured according with the tightening strategy selected.
In case of “overspeed” during the tightening operation, the
Angle result is set to 9999, and the Torque result is the peak
value, regardless of the tightening strategy.
Date / Time
Fields indicating the date and time of the tightening
operation. Date and time are taken from the date and time set
on the STwrench.
Batch status
If the batch size is left to zero, the Batch status is always OK.
If the batch size is set to one or more, the Batch status is OK
when all the Psets/Multistages of the batch are OK.
Batch number
Batch number of the Pset/Multistage (from 1 to the Batch
size).
Batch size
Batch size defined in the Pset definition.
Unit of Measurement
Unit of measurement.
Cycle start, Torque min.,
Torque and angle parameters of the Pset.
