Working with Power Focus STwrench User Guide
230 (326) 9836 4134 01 Edition 2.9
When programming a Pset in Power Focus, ensure that all of the torque parameters are higher than the
STwrench minimum load (5% of the wrench capacity), and lower than the STwrench capacity; if not, an
error is shown on Power Focus.
If a 2-stage Pset is programmed from Power Focus, the STwrench uses the torque/angle parameters of the
second stage. The first stage parameters are not considered; however, they must be set in a consistent way
(for instance, all the torque parameters must be between the STwrench minimum load and the wrench
capacity).
NOTE: For detailed Power Focus settings and operations, pl
ease refer also to the latest user
guide of Power Focus and ToolsTalk PF.
parameter specifies the automatic shutdown timeout. The timeout
specified by ToolsTalk BLM in the STwrench settings is ignored.
NOTE: When the STwrench is connected to Power Focus via the SL
Cable, this parameter is ignored and the automatic shutdown
function on the wrench is disabled.
None: Suggested settings. In case the connection is lost between
STwrench and Power Focus, the batch continues anyway, and the
STwrench returns to the “waiting Pset from Power Focus” menu.
NOTE: This setting does not support Jobs defined as “free”.
Connected: In case the connection is lost between STwrench and
Power Focus, the batch run is interrupted, and the STwrench returns
to the “waiting Pset from Power Focus” menu.
T277 TorqueAndAngle Trace
Set Power Focus to retrieve also the STwrench traces.
When this function is enabled, if the STwrench reaches the
maximum number of traces stored (which can be set in the wrench
settings) and the traces are not transferred to Power Focus (for
example, because a radio connection is temporary missing), the
STwrench goes into the “wrench locked” mode until the traces are
sent to Power Focus.
Power Focus can be also set to transfer the traces to ToolsNet.
T296 IRC-W operational mode
When the ST is connected to Power Focus via IRC-W / Access
Point, this parameter must be set to Infrastructure.
When the connection is made via IRC-W dual band module in peer-
to-peer mode, it must be set to Ad Hoc.
