STwrench User Guide Working with the QATnode
9836 4134 01 Edition 2.9 287 (326)
Disable the connection and click on Store to access the configuration menu.
Select the ToolsNet general settings inside the Accessories → QATnode menu:
The System Name, Station Name and Spindle Name identify the tree structure which is shown in
ToolsNet.
The System Number and Spindle Number are associated with the tightening results.
PIM/TCP Server settings:
• IP address: Specify the IP address of the PIM server (part of the ToolsNet configuration)
• Port: specify the port number of the PIM server (part of the ToolsNet configuration)
• Keep alive timeout: The STwrench and QATnode exchange a “keep alive” message at a certain
frequency. This parameter specifies the time interval between two messages; the default value of
1 second is recommended. However, for “slow” networks this value may be increased.
Click on Store to save the settings.
Enable ToolsNet management
NOTE: a disabling/enabling cycle
of this flag will reset any data
present in the wrench that has yet to
be transferred to ToolsNet.
