Version 7.2 505 Mediant 1000B Gateway & E-SBC
User's Manual 24. Manipulation
The following procedure describes how to configure number manipulation rules through the
Web interface. You can also configure this using the following management tools:
Destination Phone Number Manipulation for IP-to-Tel Calls table: ini file
(NumberMapIP2Tel) or CLI (configure voip > gateway manipulation dst-number-map-
ip2tel)
Destination Phone Number Manipulation for Tel-to-IP Calls table: ini file
(NumberMapTel2IP) or CLI (configure voip > gateway manipulation dst-number-map-
tel2ip)
Source Phone Number Manipulation for IP-to-Tel Calls table: ini file
(SourceNumberMapIP2Tel) or CLI (configure voip > gateway manipulation src-
number-map-ip2tel)
Source Phone Number Manipulation for Tel-to-IP Calls table: ini file
(SourceNumberMapTel2IP) or CLI (configure voip > gateway manipulation src-
number-map-tel2ip)
To configure a number manipulation rule:
1. Open the required Phone Number Manipulation table (Setup menu > Signaling &
Media tab > Gateway folder > Manipulation > Dest Number IP->Tel, Dest Number
Tel->IP, Source Number IP->Tel, or Source Number Tel->IP).
2. Click New; the following dialog box appears:
Figure 24-2: Phone Number Manipulation Table (Example) - Add Dialog Box
3. Configure a number manipulation rule according to the parameters described in the
table below.
4. Click Apply.
The table below shows configuration examples of Tel-to-IP source phone number
manipulation rules configured in the Source Phone Number Manipulation for Tel-to-IP Calls
table:
Table 24-1: Configuration Examples of Source Phone Number Manipulation for Tel-to-IP Calls
Parameter Rule 1 Rule 2 Rule 3 Rule 4 Rule 5
Destination
Prefix
03
* * [6,7,8]
