User's Manual 672 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Note:
• The Classification table is used only if classification by registered user in the
device's users registration database or by Proxy Set fails.
• If the device receives incoming calls (e.g., INVITE) from users that have already
been classified and registered in the device's registration database, the device
ignores the Classification table and uses the Routing Policy that was determined
for the user during the initial classification process.
The following procedure describes how to configure Routing Policies rules through the
Web interface. You can also configure it through ini file (SBCRoutingPolicy) or CLI
(configure voip > sbc routing sbc-routing-policy).
 To configure a Routing Policy rule:
1. Open the Routing Policies table (Setup menu > Signaling & Media tab > SBC folder
> Routing > Routing Policies).
2. Click New; the following dialog box appears:
Figure 33-8: Routing Policies Table - Add Dialog Box
3. Configure the Routing Policy rule according to the parameters described in the table
below.
4. Click Apply.
Table 33-5: Routing Policies table Parameter Descriptions
Parameter Description
General
Index Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
name
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 41 characters. By default,
no name is defined. If you don't configure a name, the device
To Next Page
