AudioCodes MediaPack MP-11 Series User Manual

Version 7.2 673 Mediant 1000B Gateway & E-SBC
User's Manual 33. Routing SBC
Parameter Description
[SBCRoutingPolicy_Name]
automatically assigns a name in the following format:
"SBCRoutingPolicy_<Index>", for example,
"SBCRoutingPolicy_2".
Note: Each row must be configured with a unique name.
LDAP Servers Group Name
ldap-srv-group-name
[SBCRoutingPolicy_LdapServer
sGroupName]
Assigns an LDAP Server Group to the Routing Policy.
Routing rules in the IP-to-IP Routing table that are
associated with the Routing Policy and that are configured
with LDAP and/or Call Setup Rules, use the LDAP server(s)
configured for this LDAP Server Group.
By default, no value is defined.
For more information on LDAP Server Groups, see
''Configuring LDAP Server Groups'' on page 232.
Note: The default Routing Policy is assigned the default
LDAP Server Group ("DefaultCTRLServersGroup").
Least Cost Routing
LCR Feature
lcr-enable
[SBCRoutingPolicy_LCREnable]
Enables the Least Cost Routing (LCR) feature for the
Routing Policy.
 [0] Disable (default)
 [1] Enable
For more information on LCR, see ''Least Cost Routing'' on
page 257.
Default Call Cost
lcr-default-cost
[SBCRoutingPolicy_LCRDefaultCost]
Defines whether routing rules in the IP-to-IP Routing table
that are not assigned a Cost Group are considered a higher
cost or lower cost route compared to other matched routing
rules that are assigned Cost Groups.
 [0] Lowest Cost = (Default) The device considers a
matched routing rule (belonging to the Routing Policy)
that is not assigned a Cost Group as the lowest cost
route. Therefore, it uses the routing rule.
 [1] Highest Cost = The device considers a matched
routing rule (belonging to the Routing Policy) that is not
assigned a Cost Group as the highest cost route.
Therefore, it is only used if the other matched routing
rules that are assigned Cost Groups are unavailable.
Note: If multiple matched routing rules without an assigned
Cost Group exist, the device selects the first matched rule in
the table.
LCR Call Duration
lcr-call-length
[SBCRoutingPolicy_LCRAverageCallL
ength]
Defines the average call duration (in minutes) and is used to
calculate the variable portion of the call cost. This is useful,
for example, when the average call duration spans over
multiple time bands. The LCR is calculated as follows: cost =
call connect cost + (minute cost * average call duration).
The valid value is 0-65533. The default is 1.
For example, assume the following Cost Groups:
 "Weekend A": call connection cost is 1 and charge per
minute is 6. Therefore, a call of 1 minute cost 7 units.
 "Weekend B": call connection cost is 6 and charge per
minute is 1. Therefore, a call of 1 minute cost 7 units.
Therefore, for calls under one minute, "Weekend A" carries
