User's Manual 680 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Least Cost Routing (LCR), you need to configure these settings for the Routing Policy
(regardless of the number of Routing Policies employed). For more information on Routing
Policies, see ''Configuring SBC Routing Policy Rules'' on page 670.
Note: The IP Groups table can be used to configure a host name that overwrites the
received host name. This manipulation can be done for source and destination IP
Groups (see ''Configuring IP Groups'' on page 333).
The following procedure describes how to configure Inbound Manipulation rules through
the Web interface. You can also configure it through ini file (IPInboundManipulation) or CLI
(configure voip > sbc manipulation ip-inbound-manipulation).
 To configure an Inbound Manipulation rule:
1. Open the Inbound Manipulations table (Setup menu > Signaling & Media tab > SBC
folder > Manipulation > Inbound Manipulations).
2. Click New; the following dialog box appears:
Figure 34-2: Inbound Manipulations Table - Add Dialog Box
3. Configure the Inbound Manipulation rule according to the parameters described in the
table below.
4. Click Apply.
Table 34-1: Inbound Manipulations Table Parameter Descriptions
Parameter Description
Routing Policy
routing-policy-name
[IPInboundManipulation_Routing
PolicyName]
Assigns an Routing Policy to the rule. The Routing Policy
associates the rule with an SRD(s). The Routing Policy also
defines default LCR settings as well as the LDAP servers if the
routing rule is based on LDAP routing (and Call Setup Rules).
If only one Routing Policy is configured in the Routing Policies
To Next Page
