User's Manual 756 Document #: LTRT-27045
Mediant 1000B Gateway & E-SBC
Note:
• To configure the User Info table, make sure that you have enabled the feature, as
described in Enabling the User Info Table on page754.
• If a User Info file is loaded to the device (as described in ''Configuring GW User
Info Table in Loadable Text File'' on page 758), all previously configured entries
are removed from the table in the Web interface and replaced with the entries from
the loaded User Info file.
 To configure the GW User Info table through the Web interface:
1. Open the GW User Info table (Setup menu > Signaling & Media tab > Gateway
folder > User Information).
2. Click New; the following dialog box appears:
Figure 43-6: GW User Info Table - Add Dialog Box
3. Configure a user according to the table below.
4. Click Apply.
5. To register a user, select the user's table entry, and then from the Action drop-down
list , choose Register. To un-register a user, select the user, and then from the Action
drop-down list , choose Un-Register.
Table 43-2: GW User Info Table Parameter Descriptions
Parameter Description
Index
[GWUserInfoTable_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
PBX Extension
[GWUserInfoTable_PBXExtension]
Defines the PBX extension number.
The valid value is a string of up to 10 characters.
Note: The parameter is mandatory.
Global Phone Number
[GWUserInfoTable_GlobalPhoneNumber]
Defines the "global" phone number for the IP side.
The valid value is a string of up to 20 characters.
Note: The parameter is mandatory.
To Next Page
