Notes:
• Before adding IP network interfaces to the Multiple Interface table, see
Multiple Interface Table Configuration Rules on page 111 for the rules on
configuring valid IP network interfaces.
• When booting using BootP/DHCP protocols, an IP address is obtained
from the server. This address is used as the OAMP address for the initial
session, overriding the address configured in the Multiple Interface table.
The address configured for OAMP applications in this table becomes
available only after you save the configuration to the device's flash with a
reset. This enables the device to operate with a temporary address for
initial management and configuration while retaining the address
configured in this table for deployment.
• The Multiple Interface table can also be configured using the table ini file
parameter, InterfaceTable (see 'Networking Parameters' on page 421).
 To configure IP network interfaces:
1. Open the IP Settings page (Configuration tab > VoIP menu > Network submenu > IP
Settings).
Figure 11-2: IP Settings Page (Single Network Interface)
Note: The IP Settings page appears only in the following circumstances:
• Upon initial configuration (i.e., IP interfaces have never been configured).
• The Multiple Interface Table button has not been clicked in any previous
access to this page and only a single IP address has been configured.
• The device has been restored to default settings.
If you have clicked the Multiple Interface Table button or have configured multiple
interfaces using any other non-Web management tool, the Multiple Interface
Table page appears instead of the IP Settings page.
2. To access the Multiple Interface table so that you can configure multiple network
interfaces, click the Multiple Interface Table button, located under the Multiple
