4.1.4 Toolbar Description
The toolbar provides frequently required command buttons, described in the table below:
Table 4-2: Description of Toolbar Buttons
Icon Button
Name
Description
Submit
Applies parameter settings to the device (see 'Saving Configuration'
on page 324).
Note: This icon is grayed out when not applicable to the currently
opened page.
Burn
Saves parameter settings to flash memory (see 'Saving
Configuration' on page 324).
Device
Actions
Opens a drop-down list with frequently needed commands:
 Load Configuration File: Opens the Configuration File page for
loading an ini file to the device (see 'Backing Up and Loading
Configuration File' on page 346).
 Save Configuration File: Opens the Configuration File page for
saving the ini file to a folder on a computer (see 'Backing Up and
Loading Configuration File' on page 346).
 Reset: Opens the Maintenance Actions page for performing
various maintenance procedures such as resetting the device
(see 'Resetting the Device' on page 321).
 Software Upgrade Wizard: starts the Software Upgrade wizard
for upgrading the device's software (see 'Software Upgrade
Wizard' on page 343).
Home
Opens the Home page (see 'Viewing the Home Page' on page 59).
Help
Opens the Online Help topic of the currently opened configuration
page (see 'Getting Help' on page 58).
Log off
Logs off a session with the Web interface (see 'Logging Off the Web
Interface' on page 59).
Note: If you modify a parameter that takes effect only after a device reset, after you
click the Submit
"Reset", as shown in the figure below. This is a reminder that you need to
later save your settings to flash memory and reset the device.
Figure 4-3: "Reset" Displayed on Toolbar
