AudioCodes MediaPack MP-118 User Manual

Version 6.6 529 MP-11x & MP-124
User's Manual 43. Configuration Parameters Reference
Parameter Description

[1] = ETSI VMWI before ring DT_AS
 [2] = ETSI VMWI before ring RP_AS
 [3] = ETSI VMWI before ring LR_DT_AS
 [4] = ETSI VMWI not ring related DT_AS
 [5] = ETSI VMWI not ring related RP_AS
 [6] = ETSI VMWI not ring related LR_DT_AS
Note: For this parameter to take effect, a device reset is
required.
EMS: Bellcore VMWI Type One
Standard
[BellcoreVMWITypeOneStandard]
Determines the Bellcore VMWI sub-standard.
 [0] = (Default) Between rings.
 [1] = Not ring related.
Note: For this parameter to take effect, a device reset is
required.
43.10.5.5 Call Hold Parameters
The call hold parameters are described in the table below.
Table 43-44: Call Hold Parameters
Parameter Description
Web/EMS: Enable Hold
[EnableHold]
Enables the Call Hold feature that allows users, connected to the device,
to place a call on hold (or remove from hold). This is done using the
phone's Hook Flash button. On receiving a hold request, the remote party
is placed on hold and hears the hold tone.
 [0] Disable
 [1] Enable (default)
Notes:
 To use this service, the devices at both ends must support this option.
 This parameter can also be configured in an IP Profile.
Web/EMS: Hold Format
[HoldFormat]
Determines the format of the SDP in the Re-INVITE hold request.
 [0] 0.0.0.0 = (Default) The SDP "c=" field contains the IP address
"0.0.0.0" and the "a=inactive" attribute.
 [1] Send Only = The SDP "c=" field contains the device's IP address
and the "a=sendonly" attribute.
 [2] x.y.z.t = The SDP "c=" field contains the device's IP address and
the "a=inactive" attribute.
Note: The device does not send any RTP packets when it is in hold
state.
Web/EMS:Held Timeout
[HeldTimeout]
Defines the time interval that the device allows for a call to remain on
hold. If a Resume (un-hold Re-INVITE) message is received before the
timer expires, the call is renewed. If this timer expires, the call is released
(terminated).
 [-1] = (Default) The call is placed on hold indefinitely until the initiator
of the on hold retrieves the call again.
 [0 - 2400] = Time to wait (in seconds) after which the call is released.
Web: Call Hold Reminder
Ring Timeout
Defines the duration (in seconds) that the Call Hold Reminder Ring is
played. If a user hangs up while a call is still on hold or there is a call

AudioCodes MediaPack MP-118 Specifications

General

Category	Gateway
Analog Ports	8 FXS ports
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Protocols	SIP, MGCP, H.323
Model	AudioCodes MediaPack MP-118
Fax Support	T.38
Management	Web-based, SNMP, CLI
Security	SRTP, TLS, HTTPS
Power Supply	AC 100-240V, 50-60Hz
Humidity	10% to 90%, non-condensing
Network Interfaces	2 x 10/100Base-T Ethernet
