Transfer request is rejected.
 When this parameter is set to [2], the XferPrefix parameter
can be used to define different routing rules for redirected
calls.
 This parameter is ignored if the parameter
AlwaysSendToProxy is set to 1.
16.2 Configuring Proxy Sets Table
The Proxy Sets Table page allows you to define Proxy Sets. A Proxy Set is a group of
Proxy servers defined by IP address or fully qualified domain name (FQDN). You can
define up to 10 Proxy Sets, each with up to five Proxy server addresses. For each Proxy
server address you can define the transport type (i.e., UDP, TCP, or TLS). In addition,
Proxy load balancing and redundancy mechanisms can be applied per Proxy Set if it
contains more than one Proxy address.
Proxy Sets can later be assigned to Server-type IP Groups (see 'Configuring IP Groups' on
page 175). When the device sends an INVITE message to an IP Group, it is sent to the IP
address or domain name defined for the Proxy Set that is associated with the IP Group. In
other words, the Proxy Set represents the destination of the call.
Notes:
• Proxy Sets can be assigned only to Server-type IP Groups.
• The Proxy Set table can also be configured using two complementary
tables:
- Proxy Set ID with IP addresses: Table ini file parameter, ProxyIP.
- Attributes for the Proxy Set: Table ini file parameter, ProxySet.
