ModemBypassPayloadType (ini file)
During the bypass period, the coder uses the packing factor, configured by the 'Fax/Modem
Bypass Packing Factor' parameter (FaxModemBypassM). The packing factor determines
the number of coder payloads (each the size of
FaxModemBypassBasicRTPPacketInterval) that are used to generate a single fax/modem
bypass packet. When fax/modem transmission ends, the reverse switching, from bypass
coder to regular voice coder is performed.
To configure fax / modem bypass mode:
1. In the SIP General Parameters page (Configuration tab > VoIP menu > SIP
Definitions > General Parameters), set the 'Fax Signaling Method' parameter to No
Fax (IsFaxUsed = 0).
2. In the Fax/Modem/CID Settings page, do the following:
a. Set the 'Fax Transport Mode' parameter to Bypass (FaxTransportMode = 2).
b. Set the 'V.21 Modem Transport Type' parameter to Enable Bypass
(V21ModemTransportType = 2).
c. Set the 'V.22 Modem Transport Type' parameter to Enable Bypass
(V22ModemTransportType = 2).
d. Set the 'V.23 Modem Transport Type' parameter to Enable Bypass
(V23ModemTransportType = 2).
e. Set the 'V.32 Modem Transport Type' parameter to Enable Bypass
(V32ModemTransportType = 2).
f. Set the 'V.34 Modem Transport Type' parameter to Enable Bypass
(V34ModemTransportType = 2).
3. Set the ini file parameter, BellModemTransportType to 2 (Bypass).
4. Configure the following optional parameters:
• 'Fax/Modem Bypass Coder Type' (FaxModemBypassCoderType).
• 'Fax Bypass Payload Type' (FaxBypassPayloadType) - in the RTP/RTCP
Settings page (Configuration tab > VoIP menu > Media > RTP/RTCP Settings).
• ModemBypassPayloadType (ini file).
• FaxModemBypassBasicRTPPacketInterval (ini file).
• FaxModemBypasDJBufMinDelay (ini file).
Note: When the device is configured for modem bypass and T.38 fax, V.21 low-
speed modems are not supported and fail as a result.
