ID associated with the IP Group.
Notes:
 If you select an IP Group, you do not need to configure a
destination IP address. However, if both parameters are
configured in this table, the INVITE message is sent only to the IP
Group (and not the defined IP address).
 If the parameter AlwaysUseRouteTable is set to 1 (see
'Configuring IP Groups' on page 175), then the Request-URI host
name in the INVITE message is set to the value defined for the
parameter 'Dest. IP Address' (above); otherwise, if no IP address
is defined, it is set to the value of the parameter 'SIP Group Name'
(defined in the IP Group table).
 This parameter is used as the 'Serving IP Group' in the Account
table for acquiring authentication user/password for this call (see
'Configuring Account Table' on page 183).
 For defining Proxy Set ID's, see 'Configuring Proxy Sets Table' on
page 178.
IP Profile ID
[PREFIX_ProfileId]
Assigns an IP Profile ID to this IP destination call. This allows you to
assign numerous configuration attributes (e.g., voice codes) per
routing rule. To configure IP Profiles, see 'Configuring IP Profiles' on
page 194.
Status
Displays the connectivity status of the routing rule's IP destination. If
there is connectivity with the destination, this field displays "OK" and
the device uses this routing rule if required.
The routing rule is not used if any of the following is displayed:
 "n/a" = The destination IP Group is unavailable
 "No Connectivity" = No connection with the destination (no
response to the ping or SIP OPTIONS).
 "QoS Low" = Poor Quality of Service (QoS) of the destination.
 "DNS Error" = No DNS resolution. This status is applicable only
when a domain name is used (instead of an IP address).
 "Unavailable" = The destination is unreachable due to networking
issues.
Web/EMS: Charge Code
[PREFIX_MeteringCode]
Assigns a Charge Code to the routing rule. To configure Charge
Codes, see Configuring Charge Codes Table on page 263.
Note: This parameter is applicable only to FXS interfaces.
Cost Group ID
[PREFIX_CostGroup]
Assigns a Cost Group with the routing rule for determining the cost of
the call. To configure Cost Groups, see 'Configuring Cost Groups' on
page 169.
Forking Group
[PREFIX_ForkingGroup]
Defines a forking group ID for the routing rule. This enables forking of
incoming Tel calls to two or more IP destinations. The device sends
simultaneous INVITE messages and handles multiple SIP dialogs
until one of the calls is answered. When a call is answered, the other
calls are dropped.
If all matched routing rules belong to the same Forking Group
number, the device sends an INVITE to all the destinations belonging
to this group and according to the following logic:
 If matched routing rules belong to different Forking Groups, the
device sends the call to the Forking Group of the first matched
