• Retain the existing configuration (ini file): Do not select an ini file, and ensure that
the 'Use existing configuration' check box is selected (default).
• Return the device's configuration settings to factory defaults: Do not select an ini
file, and clear the 'Use existing configuration' check box.
7. Click the Next button to progress to the relevant wizard pages for loading the
desired auxiliary files. To return to the previous wizard page, click the Back
button. As you navigate between wizard pages, the relevant file type corresponding to
the Wizard page is highlighted in the left pane.
8. When you have completed loading all the desired files, click the Next button until
the last wizard page appears ("FINISH" is highlighted in the left pane).
9. Click the Reset button to complete the upgrade process; the device 'burns' the
newly loaded files to flash memory and then resets the device.
Note: Device reset may take a few minutes (depending on .cmp file version, this
may even take up to 30 minutes).
After the device resets, the End of Process wizard page appears displaying the new
.cmp and auxiliary files loaded to the device.
Figure 31-6: Software Upgrade Process Completed Successfully
10. Click End Process to close the wizard; the Web Login dialog box appears.
11. Enter your login user name and password, and then click OK; a message box appears
informing you of the new .cmp file.
12. Click OK; the Web interface becomes active, reflecting the upgraded device.
