AudioCodes MediaPack MP-118 User Manual

Version 6.6 475 MP-11x & MP-124
User's Manual 43. Configuration Parameters Reference
Parameter Description
[NoAudioPayloadType]
Defines the payload type of the outgoing SDP offer.
The valid value range is 96 to 127 (dynamic payload type). The default
is 0 (i.e. NoAudio is not supported). For example, if set to 120, the
following is added to the INVITE SDP:
a=rtpmap:120 NoAudio/8000\r\n
Note: For incoming SDP offers, NoAudio is always supported.
Web: SIP Transport Type
EMS: Transport Type
[SIPTransportType]
Determines the default transport layer for outgoing SIP calls initiated by
the device.
 [0] UDP (default)
 [1] TCP
 [2] TLS (SIPS)
Notes:
 It's recommended to use TLS for communication with a SIP Proxy
and not for direct device-to-device communication.
 For received calls (i.e., incoming), the device accepts all these
protocols.
 The value of this parameter is also used by the SAS application as
the default transport layer for outgoing SIP calls.
Web: SIP UDP Local Port
EMS: Local SIP Port
[LocalSIPPort]
Defines the local UDP port for SIP messages.
The valid range is 1 to 65534. The default is 5060.
Web: SIP TCP Local Port
EMS: TCP Local SIP Port
[TCPLocalSIPPort]
Defines the local TCP port for SIP messages.
The valid range is 1 to 65535. The default is 5060.
Web: SIP TLS Local Port
EMS: TLS Local SIP Port
[TLSLocalSIPPort]
Defines the local TLS port for SIP messages.
The valid range is 1 to 65535. The default is 5061.
Note: The value of this parameter must be different from the value of
the parameter TCPLocalSIPPort.
Web/EMS: Enable SIPS
[EnableSIPS]
Enables secured SIP (SIPS URI) connections over multiple hops.
 [0] Disable (default)
 [1] Enable
When the SIPTransportType parameter is set to 2 (i.e., TLS) and the
parameter EnableSIPS is disabled, TLS is used for the next network
hop only. When the parameter SIPTransportType is set to 2 or 1 (i.e.,
TCP or TLS) and EnableSIPS is enabled, TLS is used through the entire
connection (over multiple hops).
Note: If this parameter is enabled and the parameter SIPTransportType
is set to 0 (i.e., UDP), the connection fails.
Web/EMS: Enable TCP
Connection Reuse
[EnableTCPConnectionR
euse]
Enables the reuse of the same TCP connection for all calls to the same
destination.
 [0] Disable = Uses a separate TCP connection for each call.
 [1] Enable = (Default) Uses the same TCP connection for all calls.
Note: For the SAS application, this feature is configured using the
SASConnectionReuse parameter.
Web: Fake TCP alias
[FakeTCPalias]
Enables the re-use of the same TCP/TLS connection for sessions with
the same user, even if the "alias" parameter is not present in the SIP Via
header of the first INVITE.

AudioCodes MediaPack MP-118 Specifications

General

Category	Gateway
Analog Ports	8 FXS ports
Voice Codecs	G.711, G.723.1, G.726, G.729A/B
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Protocols	SIP, MGCP, H.323
Model	AudioCodes MediaPack MP-118
Fax Support	T.38
Management	Web-based, SNMP, CLI
Security	SRTP, TLS, HTTPS
Power Supply	AC 100-240V, 50-60Hz
Humidity	10% to 90%, non-condensing
Network Interfaces	2 x 10/100Base-T Ethernet
