Software version of the logic (D6)
È
Description of the display:
LOGIC SFTWR. VER.
Display of software version of the logic
Potentiometer values (D7)
È
Description of the display:
POT. VALUE
The voltage values are displayed here if a potentiometer is installed:
in line 2 the value in end position CLOSED,
in line 3 the current value and
in line 4 the value in end position OPEN
RWG data (D8)
È
Description of the display:
RWG VALUE
The current values are displayed here if an RWG is installed:
in line 2 the value in end position CLOSED,
in line 3 the current value and
in line 4 the value in end position OPEN
100
Actuator controls
AUMATIC AC 01.1/ACExC 01.1 Profibus DP Manual


POT. VALUE D7


RWG VALUE D8


LOGIC SFTWR. VER D6
