24-31-35 Disassembly of ASSY Brush Holder
To check the length of carbon brushes no further disassembly of Brush Holder Assembly E4A-91-410-
000 is necessary.
The picture below shows the released carbon brushes.
Clean the brush holder and the brush rip with a soft brush.
Do not use a steal brush for cleaning to avoid any damage.
Fig. 24 - 34 ASSY Brush Holder
