73-00-20 Injector Seals
73-00-21 Removal of the Injectors Seals
1. Remove of the injector cover - refer to Chapter 85-00-11.
2. Remove the injector - refer to Chapter 73-00-11.
3. Remove gasket rings [1] and clean injector shaft.
73-00-22 Installation of the Injectors Seals
1. Install new gasket rings [1].
2. Install the injectors - refer to Chapter 73-00-12.
3. Install the injector cover - refer to Chapter 85-00-12.
4. Perform an engine ground run according to Chapter 71-00-03.
5. After the ground run inspect fuel system for leakage.
Fig. 73 - 2 Fig. 73 - 3
Fig. 73 - 4
Injector grease [3] is available at Austro Engine GmbH. Refer to the consumable list.
