Chapter 80-00-00 Starting
80-00-01 General
For detailed description refer to the Chapter “Operating Instructions” of the referring Operation
Manual for the engine model.
80-00-10 Starter
80-00-11 Removal of the Starter
1. Disconnect the battery – refer to the applicable Aircraft Maintenance Manual.
First disconnect the negative pole and second the positive pole.
2. Disconnect the electrical cables from the starter – refer to the applicable Aircraft
Maintenance Manual.
3. Remove the tie rap [1].
4. Remove the screws [2] from the GPC-bracket.
5. Remove the screw [3].
6. Place the GPC side wards.
7. Do not lose the spacer [4].
8. Remove the second screw at the starter.
9. Remove carefully the starter.
80-00-12 Installation of the Starter
1. Install carefully the starter.
2. Put the GPC-bracket in the correct position.
3. Screw on the screws [2] with the spacer [4].
4. Screw on the screws on the starter.
5. Torque the screws on the starter with 22 Nm.
6. Torque the screws [2] with 13 Nm.
7. Install a new tie rap [1].
8. Connect the electrical cables – refer to the applicable Aircraft Maintenance Manual.
9. Connect the battery – refer to the applicable Aircraft Maintenance Manual.
10. Perform an engine ground run according to Chapter 71-00-03.
