79-00-70 Oil-Filter
79-00-71 Remove and discard of the Oil-Filter
1. Remove oil filter by unscrewing of the oil filter cover [1].
2. Detach the oil filter from the oil filter cover by pulling them off.
3. Discard the oil filter [2].
79-00-72 Installation of the Oil-Filter
1. Use only new O-rings at the oil-filter.
2. Put on the new filter on the cover.
3. Screw down the oil filter cover with 25 Nm.
4. Clean the working area.
5. Perform an engine ground run according to Chapter 71-00-03.
6. After the ground run inspect oil system for leakage.
Fig. 79 - 5 Fig. 79 - 6
Fig. 79 - 7
