79-00-20 Drain of Engine Oil
1. Remove the safety wire [1].
2. Put a container (min. 8,5 l) below the drain plug.
3. Open the oil drain plug [2].
4. Open the Oil Dip Stick
5. Let the oil drain off.
Fig. 79 - 2
79-00-30 Refill of Engine Oil
6. Turn in the oil drain plug [2] with a new sealing ring and torque it with 30 Nm.
7. Save it with a safety wire Ø 0,81 mm.
8. Refill Engine Oil at the Oil Dip Stick Opening
9. Install Oil Dip Stick and check oil level (refer to Chapter 12-20-01)
Only use recommended engine oil according to 79-00-01 General
