79-00-84 Installation of the Oil Separator By-Pass Valve
1. Install the new by-pass valve.
2. Screw it down carefully by hand torque.
3. Use Loctite 243.
When using Loctite, make sure, that the thread is free of grease and apply only a thin
film of Loctite.
4. Install the oil separator – refer to Chapter 79-00-82.
5. Install the injector cover – refer to Chapter 85-00-12.
6. Clean the working area.
7. Perform an engine ground run according to Chapter 71-00-03.
8. After the ground run inspect oil system for leakage.
Fig. 79 - 9
Fig. 79 - 10
