76-00-50 Camshaft Sensor CAS 2
76-00-51 Removal of the Camshaft Sensor CAS 2
1. Pull down the electrical connector CAS 2.
2. Remove the locking screw from the sensor [1].
3. Pull the camshaft sensor out.
76-00-52 Installation of the Camshaft Sensor CAS 2
1. Lubricate the new O-ring with acid free lubrication.
2. Push the sensor into the sensor housing and inspect the correctly seat of the O-ring.
3. Tighten up the camshaft sensor screw with 12 Nm.
4. Inspect the correctly seat of the sensor.
5. Attach the electrical connector CAS 2.
6. Perform an engine ground run according to Chapter 71-00-03.
