85-30-55 Installation of the EGR closing cover top
1. Put the closing cover [01] next to the outlet.
2. Screw down the cover with both screws [02]. Tighten the screws with 9 Nm.
Fig. 85 - 79
85-30-56 Installation of the EGR closing cover bottom
1. Put the closing cover [01] next to the outlet.
2. Screw down the cover with both screws [02]. Tighten the screws with 21 Nm.
Fig. 85 - 80
