73-00-50 Low Fuel pressure sensor
73-00-51 Removal of the Fuel pressure sensor
1. Disconnect the cable plug connection [8] (FPS).
2. Screw out the FPS.
Whenever loosening or tightening hose connections fitted with a twin nipple, always hold
the twin nipple steady.
73-00-52 Installation of the Fuel pressure sensor
1. Use only a new sealing ring.
2. Screw on the FPS with 20 Nm.
3. Fit on the connector (FPS).
4. Perform an engine ground run according to Chapter 71-00-03
5. After the ground run inspect fuel system for leakage.
