71-50-00 Electrical Harness
71-50-01 General
The harness provides electrical interconnection between all system components. Also it is an
important part for HIRF & lightning protection.
71-50-02 General Information -> Wiring Harness
The wiring harness has to be fixed at several points to avoid harness damage caused by normal
engine operation (e.g.: due to vibration). Fixing points are marked in „ Fig. 71 - 63, Fig. 71 - 64 and
Fig. 71 - 63 “.
All connectors must be plugged in a way to avoid forces applied to the connector.
No tension on the harness is allowed at all.
Pay attention for correct interlocking of the plug and socket
connections. Inspect the correct locking of ALL connectors.
All shielding wires must be attached via electrically conducting connections to the engine block
at the actuator and sensor ends of the wiring harness. It is not allowed to shorten or to
extend the shielding wires.
No changes are allowed of the delivered wiring harness.
Only the delivered configuration is tested (EMI, lightning protection) and approved.
Exception: To avoid abrasion, mounting of protective tube is allowed.
