76-00-30 Crankshaft Sensor
76-00-31 Removal of the Crankshaft Sensor
1. Remove the electrical lines [1].”CRS1 or CRS2”.
2. Remove the screw [2].
3. Remove the crankshaft-sensors [3].
76-00-32 Installation of the Crankshaft Sensor
1. Install the crankshaft-sensors.
2. The distance between the sensor and the two mass flywheel must be 0,8 mm +/- 0,5
mm.
3. Screw down the fixing screws with 11 Nm.
4. Inspect the correctly seat from the sensors.
5. To clip the electrical line [1] “CRS1 or CRS2”.
6. Perform an engine ground run according to Chapter 71-00-03.
Fig. 76 - 2
