Maintenance Manu
al
E4
.08.
04
Issue da
te:
14
-Apr-
2015
Page:
85
-
30
Revision no: 25
Starter ring:
Traces of
wearing or damage a
t the gear tooth of the sta
rter ring. If tra
ces are present the
t
wo
-
mass-
flywheel has
to be replaced. Less
than 95% of the present
volume of each t
ooth is not accepta
ble.
If teeth are da
maged the starter has to be
checked. When damage
is indicated the
starter has to be
changed as w
ell.
Fig. 85 -
48
281
283
