Maintenance Manual
E4.08.04
Issue date: 14-Apr-2015
Page: 85-34
Revision no: 25
Before the measuring is started the spring packages at the inside of the two-mass-flywheel have to be
positioned. Therefore the flywheel has to be turned not more than three times into the desired
direction with a torque of about 350 Nm. After this the angle measuring system has to be reset to
null.
Thereafter the measuring can be done according to the following table. The measured angle values
have to be within the minimum and maximum tolerance values. The measuring direction may not be
changed during the procedure unless the spring packages will be repositioned for the change of the
direction.
Table 1: Tolerance values
Torque
[Nm]
Minimum
tolerance
[°]
Measured Value
Maximum
tolerance
[°]
Clockwise
turning
Counter-
clockwise
turning
25
2
12
50
2
18
75
7
23
100
13
29
125
18
34
150
24
40
175
29
45
200
34
50
225
36
52
250
38
54
275
39
55
300
41
57
325
43
59
350
44
60
Tolerance values have been round mathematically due to the handling at the measuring process
Mechanical Inspection Performed:
FITTER INSPECTOR
(Name, Date, Signature) (Name, Date, Signature)
