Fig. 85 - 82
Fig. 85 - 83
4. Put the front and back camshaft bearing covers [02] and [04] and the bracket [03] on the
camshafts.
Mount the camshafts stress-free. The camshafts may not be canted. Ensure that all bearings
are located on the place where they have been disassembled.
5. Evenly tighten the bearing covers and the bracket. Torque the bearing screws [06], [07] and [08]
with 12 Nm.
The camshafts have to be turned easily and smooth without any scratching after tightening
the screws.
