• Front side cover E4-A-14-000-000: Loosen all five screws of the front side cover of the
cylinder head.
Do not cant the cover whilst removing. The drain plug must not be damaged
(See drain plug at Figure 85 – 103).
Fig. 85 - 103 Drain plug at side cover
• Camshaft bearing shell from the intake camshaft on the timing chain side. Replace it by a
chain guiding bar as shown in Figure 85 – 104 (AEP-00139).
Fig. 85 - 104 Chain guiding bar (AEP-00139) mounted at the cylinder head
