• Apply oil at the slot of the cam shaft (See Figure 85 - 117) and attach the sensor cover. Apply
Loctite 243 to the screws and tighten them with correct torque.
• Tightening torque screws: 5 Nm (44 inch-Ibs.)
• Attach cylinder head cover. Fasten screws in the order as displayed in Figure 85 - 102
(numbers close to the “L”) with correct torque.
• Tightening torque screws: 12 Nm (106 inch-Ibs.).
• Attach oil returning line according to Chapter 79-00-112.
• Attach lubrication line according to Chapter 79-00-102.
• Mount injectors according to Chapter 73-00-12.
Place the injectors according to the numbers which were recorded during their
removal.
• Attach injector cover according to Chapter 85-00-11.
• Attach wiring harness according to Chapter 71-50-170.
• Attach fuel lines according to the instructions in the aircraft maintenance manual.
• Attach the intake air hoses according to the instructions in the Aircraft Maintenance Manual.
o The accomplishment of the above given instructions must be confirmed in the respective
engine log.
o Perform an engine ground run according to Chapter 71-00-03.
