External switch (RSW) inputs
Inall,theDCP31isprovidedwith12externalswitchinputs.Each
oftheseinputsaredifferentiatedbyRSW1,RSW2andsoforthto
RSW12.Onmodelswhoseoption2catalogNo.is“0”,onlyinputs
RSW1toRSW4aremounted.
(RSW:externalswitchinput)

External switch input types
ThefunctionsofRSW1to4,andRSW8to12arefixed.
ThefunctionsofRSW5to7areselectedbythesetupsetting.
External
Switch No.
Function
Detection Method
RSW1 RUN Rising edge
RSW2 HOLD Rising edge
RSW3 RESET Rising edge
RSW4 ADV Rising edge
RSW5
RSW6
RSW7
Selected by setup from the following
functions
FAST Rising edge
PV start Rising edge
AUTO/MANUAL Rising/falling edge
AT start/stop Rising/falling edge
G.Soak cancel by OR conditions Status
G.Soak cancel by AND conditions Status
Direct/reverse action switching Status
RSW8 Program No. selection Weighting 1 Status
RSW9 Program No. selection Weighting 2 Status
RSW10 Program No. selection Weighting 4 Status
RSW11 Program No. selection Weighting 8 Status
RSW12 Program No. selection Weighting 10 Status
• WithPVisvalidonlyintheprogramoperationmodeand
READYmode,andthePVstartRUNmodeisenteredregardless
ofthePVstartsettingintheprogram.Note,however,thatRUN
modeisenteredfromthestartpointoftheselectedsegmentin
READYmodewhenthereisnoSPforthePVstart.
6-9
Chapter 6. OPERATION
6 - 4 External Switch (RSW) Operations
