7-44
Chapter 7. PARAMETER SETUP

Setup data settings “
S E t
”
No. Item Code Item
Factory
Setting
User
Setting
Setting
1
C 0 1
Control action (CH1) 0 0: Reverse action (heat)
1: Direct action (cool)
[Note]
On heat/cool models, “– – – –” is dis-
played and setting is not possible.
On other models, external switch input
can invert direct/ reverse action on the
setting of
C 0 1
.
2
C 0 2
Input 1 temperature
unit
0 0: °C
1: °F
[Note]
When the input 1 range type is linear,
“– – – –” is displayed and setting is not
possible.
3
C 0 3
Input 1 range type 0 0 to 73
0 to 20: Thermocouple
32 to 40, 48 to 56: Resistance temperature
detector
64 to 73: Linear (dc current, dc voltage)
[Note]
Refer to the input 1 range table.
Operation according to a setting not
listed in this table is not xed.
4
C 0 4
Input 1 range deci-
mal point position
Not xed 0 to 3
[Note]
When the input 1 range type is non-
linear, “– – – –” is displayed and setting
is not possible.
When the input 1 range type is
changed from nonlinear to linear,
the original non-linear range values
remain.
