Azbil DCP31 User Manual

6-11
Chapter 6. OPERATION

Program selection
TheprogramcanbeselectedintheprogramoperationREADY
mode.Thetablebelowshowsprogramselectionbyexternalswitch
inputs.Twoexternalswitchstatesareprovidedforselectionofpro-
grams10to15.Whenprogramselectionbyexternalswitchinputs
issetto“0”,theprogramcanbeselectedbytheconsolekeysandby
communicationwithapersonalcomputer.
External
Switch No.
Weighting State
RSW8 1 OFF ON OFF ON OFF ON OFF ON OFF ON
RSW9 2 OFF OFF ON ON OFF OFF ON ON OFF OFF
RSW10 4 OFF OFF OFF OFF ON ON ON ON OFF OFF
RSW11 8 OFF OFF OFF OFF OFF OFF OFF OFF ON ON
RSW12 10 OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
Program No. Selection 0 1 2 3 4 5 6 7 8 9
External
Switch No.
Weighting State
RSW8 1 OFF OFF ON ON OFF OFF ON ON OFF OFF ON ON
RSW9 2 OFF ON OFF ON ON OFF ON OFF OFF ON OFF ON
RSW10 4 OFF OFF OFF OFF OFF ON OFF ON ON ON ON ON
RSW11 8 OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
RSW12 10 ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF
Program No. Selection 10 11 12 13 14 15
External
Switch No.
Weighting State
RSW8 1 OFF ON OFF ON OFF ON OFF ON OFF ON
RSW9 2 ON ON OFF OFF ON ON OFF OFF ON ON
RSW10 4 ON ON OFF OFF OFF OFF ON ON ON ON
RSW11 8 OFF OFF ON ON ON ON ON ON ON ON
RSW12 10 ON ON ON ON ON ON ON ON ON ON
Program No. Selection 16 17 18 19 0
