Azbil DCP31 User Manual

11-9
Chapter 11. SPECIFICATIONS
Item Specification
General
Specifica-
tions
Installation mode Permanently connected type controller, indoor installation, panel-
mounted
Standards compliance EN61010-1,
EN61326-1(For use in industrial locations)
During EMC testing, the reading or output may fluctuate by ±10%FS.
However, MFB will be within ±30%FS.
Over-voltage category Category II (IEC60364-4-443, IEC60664-1)
Pollution degree 2
Transport/storage
conditions
Ambient
temperature range
−20 to +70°C
Ambient humidity
range
10 to 95%RH (no condensation)
Vibration resistance 0 to 4.90m/s
2
(10 to 60 Hz for 2h each in X, Y and
Z directions)
Impact resistance 0 to 490m/s
2
(3 times vertically)
Package drop test Drop height: 60cm (1 angle, 3 edges and 6 planes;
free fall)
External fuse Rated IEC127
Cutoff speed Delayed operation type (T)
Rated voltage 250V
Rated current 1A
Terminal screw M3.5 self-tapping screw
Terminal screws
tightening torque
0.78 to 0.98N·m
Mask/case materials Mask: PC/ABS Case: PC, PC/ABS, m-PPM
Mask/case color Mask: Dark gray (Munsell 5Y3.5/1) Case: Light gray (Munsell 2.5Y7.5/1)
Installation Specially designed mounting bracket
Weight Approx. 900g
■
Accessories/option list
Item Model No. Q’ty
Standard accessories Unit indicating label N-3132 1
Mounting bracket 81405411-003 1 set (2 brackets)
User’s Manual CP-UM-1757E 1
Options
(sold separately)
Hard dust-proof cover set 81446083-001 —
Soft dust-proof cover set 81446087-001 —
Terminal cover set 81446084-001 —
Lithium battery set 81446431-001 —
Smart Loader Package SLP-P30 —
Related manuals DIGITRONIK CPL Communications CP-SP-1066E —
Smart Loader Package CP-UM-1759JE —

Azbil DCP31 Specifications

General

Type	Digital Indicating Controller
Control Method	PID control
Input Type	Thermocouple, RTD, DC voltage, DC current
Display	LED display
Communication	RS-485
Output Type	Relay, Voltage pulse, Current
Power Supply	100 to 240 VAC
Control Output	Relay contact, Voltage pulse, Current
Operating Temperature	-10 to 50°C
