Barco DP2K SLP Series

R5906848 /04 DP2K SLP Series 149
Tip: Each small manipulation of these two screws will have an impact on the light output. Keep an eye
on the photometer to spot the point where the light output is the highest.
Ignore the direction arrows underneath each screw. These arrows only reflect internal mechanics and
do not reflect the impact on the projected image.
Optical alignment
