Barco DP2K SLP Series Service Manual

R5906848 /04 DP2K SLP Series 103
1
Image 9-14
7. Is the Light Processor replaced by a new spare Light Processor?
► If yes,
1. replace the Notch Filter in the Light Pipe with the new Notch Filter included in spare part kit of the Light
Processor. See procedure “Replacing the Notch Filter”, page 127.
2. after finishing this procedure, proceed with installing and activating the LUT-SCC file of the new Light
Processor. See chapter “Spatial Color Calibration (LUT-SCC)”, page 151.
8. Close off the Light Processor compartment:
• Install the top cover plate.
• Install the side cover plate.
• Install the top cover of the projector.
• Install the left side cover of the projector.
9.6 Cleaning the Prism exit side
When should one clean the Prism exit side?
Clean the Prism exit on a regular basis to maintain light output level.
This procedure requires that the lens is removed from the projector.
Required tools
• Compressed air.
• Clean Toraysee® cloth or any micro fiber lens cleaning cloth.
Required parts
Lens cleaner (e.g. Carl Zeiss lens cleaner or Purasol® or any water based lens cleaner)
Light Processor
