Barco DP2K SLP Series Service Manual

R5906848 /04 DP2K SLP Series26
3.1 1 month maintenance actions
MAINTENANCE TYPE A (perform every month)
The 1 month maintenance actions, listed below, may be performed by a trained projectionist who is
familiar with potential hazards associated with the product.
No. Maintenance action Remarks
1 Check both dust filters of the projector for dust and grease.
Grease on the filter can build up after several months in an
environment contaminated with greasy air. Note that areas where
popcorn is consumed are subject to greasy air.
• If the filters are contaminated with dust than cleaning the filters
with a vacuum cleaner should be sufficient.
• In case the filters feel greasy than the filters must be washed.
Take into account that the time needed to dry the dust filters may
be 24 hours or more. For that, it's recommended to have a second
set of dust filters which can be used while cleaning the first set.
Replace damaged filters
immediately.
See procedures “Check the
large dust filter”, page 284, and
“Check the small dust filter”,
page 285.
To speed-up drying, allow the
filter(s) to dry at 50°C max in a
well ventilated room.
2 Check the surface of the lens output side for dust. (it is not needed
to remove the lens from the projector). Only clean if necessary.
Clean the lens output side in
case dust is clearly visible upon
the surface.
Note: if the lens was removed
from the projector, a manual
“Lens Home & Return” action
must be executed to calibrate
the position of the lens in
relation to the Lens Holder. This
way the references of the
existing 'lens files' remain valid.
See user guide of the
Communicator software.
3 Check the porthole (both sides) for dust. Clean the porthole in case dust
is clearly visible upon the
surface. Use an optical cloth.
3.2 3 month maintenance actions
MAINTENANCE TYPE B (perform every three months)
The 3 month maintenance actions, listed below, may be performed by a trained projectionist who is
familiar with potential hazards associated with the product.
No. Maintenance action Remarks
1 Clean the back/side air inlet vents of the Light Source. Use a vacuum cleaner.
2 Clean the housing of your projector. Removal overall dust
accumulation on projector
covers. See cleaning
instructions in this manual.
3 Verify the internal clock of the ICMP with real time clock. Correct if
needed.
ICMP version 1.2.1 is required.
Communicator version 5.0 is
required.
See user guide of
Communicator for detailed
instructions.
Preventative maintenance actions
