9. Install the Anode Fan assembly into the projector. Ensure that both teeth (reference 5 Image 7-52) at the
bottom of the Anode Fan assembly are engaged in the foreseen slots in the projector chassis.
Caution: Take care that no electrical wires get pinched between the Anode Fan assembly and the
projector chassis.
10. Secure the Anode Fan assembly with two screws (reference 4 Image 7-52). Use a 3mm Allen wrench.
11. Reconnect the wire of the Anode Fan (reference 1 Image 7-51) and guide the wire into the wire clamp
(reference 2 Image 7-51).
12. Insert the convergence flex cable into the cable clamp (reference 3 Image 7-51) which is attached to the
Anode Fan assembly.
Note: One flex cable is engaged into the cable clamp, while the other is retained by the cable tie which
should be located between knob and cable clamp.
13. Install the top cover plate of the Light Processor compartment and the projector top cover.
7.18 Replacement of the Cathode Fan
To replace the Cathode Fan the Light Source has to be removed first. This procedure assumes that
Light Source is already removed.
Required tools
• Allen wrench 2.5 mm
• Allen wrench 3 mm
How to replace the Cathode Fan?
1. Remove the two fixation screws at the top of the Cathode Fan assembly (reference 1 Image 7-54). Use a 3
mm Allen wrench.
2. Gently remove the Cathode Fan assembly from the projector chassis.
Note: The Cathode Fan assembly is still connected with its wire.
Laser Phosphor Light Source
To Next Page
