Barco DP2K SLP Series Service Manual

R5906848 /04 DP2K SLP Series166
15.1 Color calibration
About this chapter
This chapter describes the luminance and color calibration process for the DP2K-SLP Series. Where
applicable references are made to the user guide of the Communicator for detailed menu navigation
instructions. The first chapter describes the complete calibration process in chronological order.
Color calibration should be executed during the installation of the projector and also after some
service actions as mentioned in the service manual.
Overview
•
Calibration process
• White point calibration
• Color gamut calibration
15.1.1 Calibration process
Overview
1. Select the desired aspect ratio by activating the correct lens file.
• SCOPE format
• FLAT format
2. Laser white point calibration.
3. The Communicator contains a wizard for white point calibration. See user guide of the Communicator for
detailed menu navigation instructions.
4. Color gamut calibration. (electronic P7 correction). Measured values are saved in the Measured Color
Gamut Data (MCGD) file. Needs to be done per format and per projection mode.
• 2D
• External 3D
5. Select target colors. The target colors are stored in the Target Color Gamut Data (TCGD) file. Several TCGD
files are already available in the file system of the projector.
6. For more info about color gamut calibration see “Color gamut calibration”, page 167. The Communicator
software contains a wizard for color gamut calibration. See user guide of the Communicator for detailed menu
navigation instructions.
7. Verify corrected colors.
8. For detailed instructions on how to verify corrected colors see user guide of Communicator.
9. Arrange calibration files in macro. To apply correct color calibration it is important that the MCGD file(s) and
matching TCGD file(s) are activated after that the INPUT file and PCF file are activated. For that it is
recommended to create a macro where the files are loaded one by one in the right order:
1. First activate the INPUT file.
2. then activate the PCF file (PCF already contains plane 1 information),
3. then activate the MCGD and TCGD files.
10. For detailed instructions on how to create a macro see Communicator's user guide.
15.1.2 White point calibration
About white point calibration
White point calibration should be executed to correct a color shift during dimming. The white point will be
stabilized over the full dimming range.
Color calibration & Light measurements
