R5906848 /04 DP2K SLP Series 349

Code 20103: “LLS – Bank 3 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20104: “LLS – Bank 4 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20105: “LLS – Bank 5 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20106: “LLS – Bank 6 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20107: “LLS – Bank 7 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20108: “LLS – Bank 8 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20109: “LLS – Bank 9 is off”

For this error the same troubleshooting table can be applied to as for code 20101: “LLS – Bank 1 is off”.

Code 20128: “LCB – FCB forces lasers off at start-up”

For this error the same troubleshooting table can be applied to as for code 20070: “LCB – FCB forces lasers

off”.

Code 20129: “LLS – Phosphor wheel motor speed too low at start-up”

For this error the same troubleshooting table can be applied to as for code 20046: “LCB – Phosphor wheel

motor speed too low”.

Code 20131: “LCB – Turn-on LCM 1 failed”

Situation Solution

Light Source cooling could not

be switched on during startup

sequence

• Check / reseat the communication cable between the LCB (J600) and

the light source fan interconnection board (J101).

• Upgrade the software to the latest version. See procedure “Software

update via Communicator (DC update companion)”, page 249.

• If problem persists, replace the fan interconnection board. See service

procedure “Replacing the Light Source Fan Interconnection Board”,

page 72.

Code 20133: “LCB – Turn-on PFC LDM 1 failed”

Situation Solution

PFC (+380 VM / VMA) could

not be switched on during the

startup process of the

projector.

• Check / reseat the power connection to the LDM.

• If problem persists, replace the LDM. See service procedure

“Replacing a Laser Drive Module”, page 56.
