Spare parts and accessories
Manual b maXX
®
BM1000
Document No. 5.07003.04
121
of 174
B
B.1.2 Chopper units BM1-BTE
- in progress -
for further information please contact your nearest Baumüller representative.
m Specification
Model BM1- BTE-23
230 V series
BTE-46
460 V series
Max. motor power (kW) 1.5 1.5
Output rating
Max. peak discharge current
(A) 10
% ED
3.6 1.8
Continuous discharge cur-
rent (A)
1.141 0.57
Braking start-up voltage
(DC)
328 V/345 V/362 V/
380
V/397 V/415 V
±3 V
656 V/690 V/725 V/
760
V/795 V/830 V
±6 V
Input rating
DC Voltage 200 to 400 V
DC
400 to 800 V
DC
Protection
Heat sink overheat Temperature over +95 °C
Power charge display Blackout until bus (+~-) voltage below 50 V
DC
Environment
Installation location Indoor (no corrosive gases, metallic dust)
Operating temperature -10 to +50
Storage temperature -20 to +60
Humidity 90 % R.H., non-condensing
Vibration 9.8m/s
2
(1G) under 20Hz
2m/s
2
(0.2G) at 20 ~ 50Hz
Mechanical configuration Wall-mounted enclosed type IP20
