Mounting
Manual b maXX
®
BM1000
Document No. 5.07003.04
35
of 174
5
5.3 Prepare mounting
You can prepare the mounting with the configuring manual for your installation. With the
project manual and the drill figures (see
ZDimensions– from page 39) you can determine
the dimensions for the cut-outs and for the fastening drills.
h Please carry only fully assembled b maXX
®
1000 to prevent machine damage.
h Execute the drilling and if necessary the cut-outs.
h Mount the b maXX
®
1000 vertically on a flat vertical surface by using bolts or screws.
Other directions are not allowed.
h The b maXX
®
1000 will generate heat during operation. Allow sufficient space around
the unit for heat dissipation.
h The heat sink temperature may rise to 90°C when running. The material on which the
b maXX
®
1000 is mounted must be noncombustible and be able to withstand this high
temperature.
h When the device is installed in a confined space (e.g. cabinet), the surrounding tem-
perature must be within 10 to 40°C with good ventilation. DO NOT install the device in
a space with bad ventilation.
h When installing multiple devices b maXX
®
1000 in the same cabinet, they should be
adjacent in a row with enough space. When installing one b maXX
®
1000 below an-
other one, use a metal separation barrier between the b maXX
®
1000 to prevent mu-
tual heating. Refer to figure below for details.
h Prevent fiber particles, scraps of paper, saw dust, metal particles, etc. from adhering
to the heatsink.
CAUTION
The following can occur, if you disregard this warning instruction:
m minor to medium personal injury.
The danger is: Eye injury due to catapulting particles. While executing the drillings and the
cut-out metal particles are catapulted.
Wear eye protection
