Requirements to the executing personnel
Manual b maXX
®
BM1000
Document No. 5.07003.04 Baumüller Nürnberg GmbH
72
of 174
7.2
7.2 Requirements to the executing personnel
At each case qualified personnel are persons, who are authorized by the responsible per-
sons, to execute necessary actions and who recognize the possible dangers and who are
able to avoid these dangers. They have had the training, the experience, they were given
instructions as well as knowledge about the relevant standards and instructions, they
have knowledge of the accident prevention regulations and of the operating environ
-
ments. The required qualifications for the work with this unit are for example:
m Education or instruction or to have the authorization to put into operation, ground and
label circuits and devices according to the standards of safety engineering.
m Training or instruction due to the standards of the safety engineering in maintenance
and use of appropriate safety equipment.
7.3 LEDs
There are three LEDs on the front of the b maXX
®
when using no optional digital keypad:
H1: READY
It will light up after applying power.
The light won’t be off until the capacitors are discharged to safe voltage levels after
power off.
H2: b maXX
®
drive status
It will light up green, when the drive is in status operation enabled.
It will light up red, when the drive is in error status.
H3: CANopen status
It will light up green, when the CANopen is in operation.
It will light up red, when CANopen is in status bus off.
WARNING
The following may occur, if you disregard these safety notes:
m serious personal injury m death
The danger is: electricity.When operating with this electrical unit, inevitably certain parts of
this unit are under dangerous voltage.
Assure, that only qualified personnel work on this unit.
H1 H2 H3
